Scope of Application:The FZN25-12 is an indoor 12kV, 50Hz/60HZ three-phase AC high-voltage load switchgear. It fits power distribution systems in industrial plants, substations, commercial buildings and mines, mainly for load current switching, closed-loop operations, and controlling no-load transformer/cable charging currents. Ideal for RMUs, terminal power units and compact substations, it enables electrical distribution, control and protection.

Rated Voltage:15KV,12kV,11KV,10KV (compliant with IEC 60298)
Rated Current: Standard models: 630A (base type), 125A/200A (fuse-combination type)
Power Frequency Withstand Voltage: 42kV (r.m.s.) phase-to-earth/phase-to-phase; 48kV (r.m.s.) across isolation gap
Lightning Impulse Withstand Voltage: 75kV (peak) phase-to-earth/phase-to-phase; 85kV (peak) across isolation gap
Breaking Capacity:Active Load Current: 630A; Cable Charging Current: 10A; No-Load Transformer Capacity: 1600kVA; Fuse-Assisted Short-Circuit Breaking: 31.5kA

Scope of Application：The KYN61-40.5 is a switchgear for three-phase AC 50Hz systems (40.5kV). It provides power distribution, protection, and control in power plants, substations, and industries, especially where frequent operation or high reliability is needed, like data centers, metallurgy, and chemical plants.

Rated Voltage: 24kV, 33KV，36kV, 40.5kV).
Rated Current: 1250A, 1600A, 2000A, 2500A, 3150A.
Rated Short-Circuit Breaking Current: 25kA, 31.5kA, 40kA.
Rated Short-Time Withstand Current: 25kA/4s, 31.5kA/4s, 40kA/4s.
Protection Degree: Enclosure IP4X, Compartment IP2X.
Internal Arc Classification: IAC-AFLR 40kA/1s (IEC 62271-200).

Scope of Application:The XGN17-40.5 is an indoor AC switchgear for 40.5kV systems (IEC 36kV level). Used in power plants, substations, and industrial facilities, it handles power reception, distribution, control, protection, and monitoring. It supports single-bus or single-bus with bypass configurations and is designed for critical operations needing high reliability.

Rated Voltage: 33KV,34.5KV,35KV,36KV
Rated Current: Main bus 1250A/1600A/2000A/2500A; Feeder bus 630A/1250A/1600A/2000A
Insulation Parameters: Power frequency withstand voltage 95kV (1min); Lightning impulse withstand voltage 185kV
Control Supply: DC 24V/48V/110V/220V; AC 110V/220V

Scope of Application:The High Voltage Shore Connection (HVSC) System supplies shore power to ocean-going vessels (e.g., container ships, cruise liners, Ro-Ro) during port berthing. It replaces onboard auxiliary generators, enabling zero-emission operations and compliance with IMO regulations and international port environmental standards.

Rated Voltage:; Secondary: 6kV, 6.6kV, 10kV, 11kV ,13.8kV, 15kV (Per IEC 60038)
Frequency: 50Hz / 60Hz (Auto-sensing or configurable)
Rated Current: 200A–2500A (Tiered per power demand)
Short-Circuit Capacity: ≥25kA (IEC 62271-200 compliant)
Ingress Protection: IP56 (Dust-tight & powerful water jet protection)
Cooling Method: Forced Air (AN) or Natural Convection (AF)
Insulation Class: Class E or higher (IEC 60085)

 Scope of Application ：MV/HV Marine Switchboard operates ship and offshore power systems (0.4kV-15kV, 50/60Hz AC). It controls power distribution on main, emergency, and section boards, and protects large equipment like propulsion, thrusters, and pumps. It withstands harsh marine conditions including humidity, salt spray, vibration, and tilt.

Voltage Levels :3.3kV, 6.6kV, 7.2kV, 11kV, 12kV, 13.8kV, 15kV
Rated Current: 630A, 1250A, 1600A, 2500A, 4000A
Rated Short-Circuit Breaking Capacity (IEC 62271-100): 25kA, 31.5kA, 40kA, 50kA
Rated Short-Time Withstand Current (1s/3s): Matches breaking capacity ratings
IP Rating (IEC 60529): IP44 (indoor), IP56 (open deck)
Insulation Medium: Air-insulated (AIS) or SF₆ gas-insulated (GIS, for compact HV designs)

Scope of Application：High-Voltage PV Grid-Connection Switchgear is used at the grid connection points of large-scale or distributed PV systems. It acts as the central unit between the step-up transformer’s high-voltage output (typically 10kV–36kV) and the public grid, managing power transfer, providing protection, enabling real-time monitoring, and ensuring grid code compliance.

Rated Voltage (Ur): 10KV,11KV,12kV,17.5kV,24kV,33KV,36kV (Internationally prevalent levels);
Power Frequency Withstand Voltage (1 min): 28 kV (12kV system), 38 kV (24kV system), 70 kV (36kV system);
Lightning Impulse Withstand Voltage (BIL): 95 kV (12kV), 125 kV (24kV), 170 kV (36kV);
Rated Current (Ir): 630 A to 4000 A (Selected based on PV array capacity);
Rated Short-Time Withstand Current (Icw): 25 kA to 50 kA for 1s to 4s;

Scope of Application：High-voltage motor control switchgear (3.3kV-15kV) controls, protects, and intelligently manages large industrial motors (like pumps and compressors) in heavy industries such as petrochemicals, power generation, and mining. metallurgy, and mining.

Rated Voltage: 3.3kV, 6.6kV, 7.2kV, 11kV, 12kV, 13.8kV, 15kV (compliant with IEC 62271-1/IEEE C37.04).
Rated Current: 400A to 5000A.
Rated Short-Circuit Breaking Capacity: 25kA/40kA (1s or 3s short-time withstand current).
Power Frequency Withstand Voltage: 28kV (12kV systems) / 38kV ( 15kV systems).
Lightning Impulse Withstand Voltage: 75kV (12kV) / 95kV (15kV systems).

Scope of Application：Suitable for the starting, stopping, protection, control, and monitoring of industrial three-phase asynchronous motors with rated voltages up to AC 1000V.

Rated Voltage (Ue): AC 380V, 400V, 415V, 440V, 480V, 660V, 690V (compliant with IEC 60439 / IEC 61439).
Rated Insulation Voltage (Ui): ≥ AC 690V / 1000V.
Rated Current (Ie): Covers motor power range (typical: 0.37kW – 630kW).
Rated Short-Time Withstand Current (Icw): Typically 15kA / 1s, 20kA / 1s, 25kA / 1s, 35kA / 1s, 50kA / 1s (to be specified).
Control Circuit Voltage: AC 110V/230V, DC 24V/110V/220V (to be specified).

Scope of Application: Designed for power plants, substations, and industrial distribution systems at altitudes above 1,000 meters, facilitating power distribution, equipment protection, and control in medium-high voltage (3.6kV–40.5kV) grids under high-altitude insulation and thermal constraints.

Rated Voltage Levels:Medium Voltage: 3.6kV, 7.2kV, 12kV, 24kV (IEC 62271-1)/High Voltage: 40.5kV (IEC 62271-200)
Insulation Levels:Power-frequency withstand voltage (1min): Per IEC 60694, e.g., ≥28kV for 12kV switchgear (sea-level value), adjusted for altitude;Lightning impulse withstand voltage: e.g., ≥75kV for 12kV switchgear (sea-level value).
Rated Current: 630A, 1250A, 1600A, 2000A, 2500A, 3150A, 4000A (IEC 62271-1).
Altitude Derating Factor: >1,000 meters; insulation strength decreases by 1% per 100m altitude increase (IEC 60694).

One-Sentence Summary:High-voltage fire-resistant switchgear is designed for electrical systems rated up to 10kV, providing fire-resistant power distribution, protection, and control in high-fire-risk installations such as substations, industrial plants, and high-rise buildings.

Rated Voltage: 7.2kV, 12kV, 24kV (per IEC 62271-1)
Rated Current: 630A, 1250A, 2500A, 3150A
Rated Short-Circuit Breaking Current: 20kA, 25kA, 31.5kA, 40kA
Insulation Level:Power Frequency Withstand Voltage: 42kV/1min (for 12kV switchgear)/Lightning Impulse Withstand Voltage: 75kV (for 12kV switchgear)
Ingress Protection (IP): IP4X (enclosure) / IP2X (operating front) (IEC 60529)
Fire Resistance Rating: ≥1 hour (passing IEC 60695 fire resistance tests)
